R400 4 sensor system
Features:
R400 & R600 series parking sensor systems are the
new generation design with dual CPU & 4 individual
channels to detect obstacles behind vehicles.
R400 & R600 parking sensor system can be attached
to an optional VDI module (Voice Distance Indicator).
NGD (No ground-detecting) technology: the ultrasonic
beam is of excellent flat shape, the obstacle lower than
1cm cannot be detected to offer more precise readings.
Unique ultrasonic resistance function can filter
environmental
ultrasonic wave effectively.
System has sensitive adjustment feature to avoid false
alarms.
Display with high brilliance under bright environment with
the fine LED or HUD display. (Heads-Up Display)
All plugs are sealed in the control box; dustproof,
water proof, free of condensation and thus longer lasting.
Universal control box can be connected to LED or HUD
visual display & add on optional Voice Distance
Indicator(VDI).
The new sensor is designed with a spring clip to allow
for easy installation.
Specification:
Working voltage: DC 10~15 V
Fuse: Inside self-recovering fuse
Distance detection: 0.3~2.0m or 1~6 feet
Display: LED 4 channels indicator with
numeric (Dash or Up mount)
Working temperature: -40 ~ 80 oC
|
|
 |
The all new HUD multi functions display
parking sensor system
Heads-Up Display is a device that using
advanced military jet technology;
it allows you to keep your eyes on the
road rather than watching the speedometer
or distance behind car when you reverse.
The display projects a digital image of
your vehicle speed right on the windshield.
No more glancing down at the instrument
panel or display unit to see how fast
you're going or how close to the object
behind the car when you backing up.
Auto-i has developed a unique and patented
system of low-cost HUD multi function
parking sensor system using the technology
developed originally for higher cost
military applications.
The advanced Auto-i HUD system makes it
possible for the driver to view information
normally found on gauges within the car
without looking away from the road.
Feature:
-Extra thin projected screen, to display
all information at lower left quarter of
front windshield.
Display Include:
Back-up distance display,
Vehicle speed display with over speed
warning Beep,
Battery voltage display,
Time display.
-Super bright colorful projection is
clear and luminous, also used under
sunlight adjust brightness automatically.
-Inversed grafting protection and
automatic recovery fuse build in.
-Self test function activated by reverse gear
- All weather & heavy rainproof design.
-Anti-false alarm (NGD) technology
-Metric-English conversions distance display
-Beep volume adjustment
-Optional VDI (Voice Distance Indicator)
Technical specifications:
Working voltage:DC 10~15 V
Fuse: Inside self-recovering fuse
Distance detection: 0.3~2.0m or 1~6 feet
Display: Multi function Heads-Up (HUD) Display
Working temperature: -40 ~ 80 oC
|
|
